Busch · MINK MV 0040–0080 E ECOTORQUE

MINK MV 0060 E ECOTORQUE

Data coverage & sourcesCompare this modelAsk about this model
ClawOil-freeOEM data10 values carry a verification flag
Busch MINK MV 0060 E ECOTORQUE

Image: Busch

Pumping speed
60 m³/h
Ultimate pressure
40 mbar
Noise level
68 dB(A)
Weight
86.2 kg

Headline ratings converted to common units for comparison; the table below shows each figure exactly as published.

Technical data

Source: Busch product page · retrieved 2026-10-01
As publishedISO 50 HzISO 50 Hz; (motor and fan)ISO 50 Hz; (ISO 3744), 1 m distance, at medium loadISO 50 Hz; approx.ISO 50 Hz; (L x W x H)ISO 60 HzISO 60 Hz; (motor and fan)ISO 60 Hz; (ISO 3744), 1 m distance, at medium loadISO 60 Hz; approx.ISO 60 Hz; (L x W x H)US 60 HzUS 60 Hz; (motor and fan)US 60 Hz; (ISO 3744), 1 m distance, at medium loadUS 60 Hz; approx.US 60 Hz; (L x W x H)
Nominal pumping speed
Pumping speed
60 m³/h m³/h
oem verified
Source · 2026-10-01
60 m³/h m³/h
oem verified
Source · 2026-10-01
35.3 ACFM ACFM
oem source
Source · 2026-10-01
Ultimate pressure
40 hPa (mbar) hPa (mbar)
oem verified
Source · 2026-10-01
40 hPa (mbar) hPa (mbar)
oem verified
Source · 2026-10-01
30 TORR TORR
oem source
Source · 2026-10-01
Power consumption (motor and fan)
Power consumption
1.4 kW kW
oem verified
Source · 2026-10-01
1.4 kW kW
oem verified
Source · 2026-10-01
2.3 hp hp
oem source
Source · 2026-10-01
Nominal motor speed
Speed
1200 – 4200 min⁻¹ min⁻¹R
Needs review · excluded from comparison
Source · 2026-10-01
1200 – 4200 min⁻¹ min⁻¹R
Needs review · excluded from comparison
Source · 2026-10-01
1200 ... 4200 rpm rpm
oem source
Source · 2026-10-01
Sound pressure level (ISO 3744), 1 m distance, at medium load
Noise level
66 dB(A) dB(A)
oem source
Source · 2026-10-01
66 dB(A) dB(A)
oem source
Source · 2026-10-01
68 dB(A) dB(A)
oem source
Source · 2026-10-01
Oil capacity
0.6 l l
oem source
Source · 2026-10-01
0.6 l l
oem source
Source · 2026-10-01
0.63 qts. qts.
oem source
Source · 2026-10-01
Weight approx.
Weight
85 kg kg
oem verified
Source · 2026-10-01
85 kg kg
oem verified
Source · 2026-10-01
190 Lbs. Lbs.
oem source
Source · 2026-10-01
Dimensions (L x W x H)
Dimensions
610 x 345 x 370 mm mm
oem source
Source · 2026-10-01
610 x 345 x 370 mm mm
oem source
Source · 2026-10-01
24 x 13.6 x 14.6 inches inches
oem source
Source · 2026-10-01
Gas inlet
Inlet connection
G 1¼"
oem source
Source · 2026-10-01
G 1¼"
oem source
Source · 2026-10-01
G 1 ¼"
oem source
Source · 2026-10-01
Gas outlet
Outlet connection
G ¾"
oem source
Source · 2026-10-01
G ¾"
oem source
Source · 2026-10-01
G ¾"
oem source
Source · 2026-10-01

Original extracted values are shown with their source and review status. Multiple values under the same condition remain separate for review.

R a min–max range as published, not a single rating

Same family: MINK MV 0040 E ECOTORQUE, MINK MV 0080 E ECOTORQUE
