Gast · 5LCA-10-M530X

5LCA-10-M530X

Data coverage & sourcesCompare this modelAsk about this model
ReciprocatingOil-freeOEM data
Weight
18.1 kg
Free air delivery
9.34 m³/h
Max. pressure
3.45 bar
Noise level
75 dB(A)

Headline ratings converted to common units for comparison; the table below shows each figure exactly as published.

Technical data

Source: Gast product page · retrieved 2026-10-05
As publishedValue60 Hz[lb][kg]60 Hz; [cfm]60 Hz; [lpm][psi][Bar][DBA][in][mm]
HP
Motor power
0.75
oem source
Source · 2026-10-05
Amps
6.8/3.4 /3.4
oem source
Source · 2026-10-05
Weight [lb]
Weight
40 lb
oem source
Source · 2026-10-05
Weight [kg]
Weight
18 kg
oem source
Source · 2026-10-05
Open Flow [cfm]
Free air delivery
5.5 cfm
oem source
Source · 2026-10-05
Open Flow [lpm]
Free air delivery
156 lpm
oem source
Source · 2026-10-05
Voltage
115/230 /230
oem source
Source · 2026-10-05
Regulatory
N/A
oem source
Source · 2026-10-05
Max Pressure [psi]
Max. pressure
50 psi
oem source
Source · 2026-10-05
Max Pressure [Bar]
Max. pressure
3.45 Bar
oem source
Source · 2026-10-05
Phase
Single Phase
oem source
Source · 2026-10-05
COO
US
oem source
Source · 2026-10-05
Sound Level [DBA]
Noise level
75 DBA
oem source
Source · 2026-10-05
Dimensions [in]
Dimensions
14.96 L x 11.81 W x 8.3 H L x 11.81 W x 8.3 H in
oem source
Source · 2026-10-05
Dimensions [mm]
Dimensions
380.0 L x 300.0 W x 210.8 H L x 300.0 W x 210.8 H mm
oem source
Source · 2026-10-05

Original extracted values are shown with their source and review status. Multiple values under the same condition remain separate for review.

Reviewed operating performance · 60 Hz

Loading reviewed performance…

Service parts · 94

Kit5
Seals and gaskets6
Piston and diaphragm parts29
Valves15
Filtration3
Fittings and hardware12
Rotating parts8
Housing and covers8
Other parts8

Part numbers from Gast’s parts lists, shop and instruction manuals. Open a part for its other models, replacements and suppliers.

Compare with another model

Parts diagrams

Exploded views from Gast’s own documents, with each position and part number as printed. Select a part to see what it fits, who sells it and what replaces it.

Model 1HAB - exploded view · O&M Manual: PISTON_70-2100_M-13.pdf, page 1410 positions

The positions on this drawing haven’t been placed yet: choose a position in the list for its part. Drag to move, pinch or Ctrl + scroll to zoom.

Select a part on the drawing or in the list to see its number, what it fits and where to get it. Turn on “select several” to build one quote for many parts.

Pos.Part numberDescriptionQty
B300AFilter
B300FFILTER
AS100CSAFETY VALVE
AS100ESAFETY VALVE
AS100GSAFETY VALVE
AF508CYLINDER HEAD
AH691CYLINDER HEAD
AF529PLATE VALVE
AK779PLATE VALVE
AF509CYLINDER
AF510CYLINDER
AF560APISTON ROD ASSEMBLY
AF560BPISTON ROD ASSEMBLY
AF560EPISTON ROD ASSEMBLY
AF560FPISTON ROD ASSEMBLY
AF560HPISTON ROD ASSEMBLY
AK893BPISTON ROD ASSEMBLY
AK893EPISTON ROD ASSEMBLY
AK893MPISTON ROD ASSEMBLY
AF517ACOUNTER WEIGHT
AF517BCOUNTER WEIGHT
AF517CCOUNTER WEIGHT
AF517DCOUNTER WEIGHT
AF517ECOUNTER WEIGHT
AK780ACOUNTER WEIGHT
AK780ECOUNTER WEIGHT
AT780BCOUNTER WEIGHT
AB136FLAT KEY
AF524FLAT KEY
AF533FAN
AF547FAN
AF534SHROUD
AT343SHROUD

Positions and part numbers as printed in Gast’s O&M Manual: PISTON_70-2100_M-13.pdf, page 14 · view the source document

Model 1VBF - exploded view · O&M Manual: PISTON_70-2100_M-13.pdf, page 169 positions

The positions on this drawing haven’t been placed yet: choose a position in the list for its part. Drag to move, pinch or Ctrl + scroll to zoom.

Select a part on the drawing or in the list to see its number, what it fits and where to get it. Turn on “select several” to build one quote for many parts.

Pos.Part numberDescriptionQty
B300AFilter
B300FFILTER
AS100CSAFETY VALVE
AS100DSAFETY VALVE
AS100ESAFETY VALVE
AS100GSAFETY VALVE
AS100HSAFETY VALVE
AF507CYLINDER HEAD
AF508CYLINDER HEAD
AF529PLATE VALVE
AF543PLATE VALVE
AF509CYLINDER
AF510CYLINDER
AF560APISTON ROD ASSEMBLY
AF560BPISTON ROD ASSEMBLY
AF560CPISTON ROD ASSEMBLY
AF560DPISTON ROD ASSEMBLY
AF560EPISTON ROD ASSEMBLY
AF560FPISTON ROD ASSEMBLY
AF561APISTON ROD ASSEMBLY
AF561BPISTON ROD ASSEMBLY
AF561CPISTON ROD ASSEMBLY
AF561DPISTON ROD ASSEMBLY
AF561EPISTON ROD ASSEMBLY
AF561FPISTON ROD ASSEMBLY
AF561JPISTON ROD ASSEMBLY
AF561NPISTON ROD ASSEMBLY
AB136DCOUPLING KEY
AB136FSQUARE KEY
AF524FLAT KEY
AH984FLAT KEY
AF533FAN
AF547FAN
AF747FAN ASSEMBLY-CW
AF535SHROUD
AF549SHROUD
AF656SHROUD

Positions and part numbers as printed in Gast’s O&M Manual: PISTON_70-2100_M-13.pdf, page 16 · view the source document

Model pab - exploded view · O&M Manual: PISTON_70-2100_M-13.pdf, page 1813 positions

The positions on this drawing haven’t been placed yet: choose a position in the list for its part. Drag to move, pinch or Ctrl + scroll to zoom.

Select a part on the drawing or in the list to see its number, what it fits and where to get it. Turn on “select several” to build one quote for many parts.

Pos.Part numberDescriptionQty
B300AFilter
B300FFILTER
AS100GSAFETY VALVE
AS100HSAFETY VALVE
AF507CYLINDER HEAD
AF508CYLINDER HEAD
AF529PLATE VALVE
AF543PLATE VALVE
AF509CYLINDER
AF510CYLINDER
AF560BPISTON ROD ASSEMBLY
AF561APISTON ROD ASSEMBLY
AF561DPISTON ROD ASSEMBLY
AF560BPISTON ROD ASSEMBLY
AB140CPULLEY
AK670PULLEY
B140CPULLEY
AF517BCOUNTER WEIGHT
AB136FLAT KEY
AF524FLAT KEY
AF533FAN
AF547FAN
AF661FAN
AF534SHROUD
AF535SHROUD
AF549SHROUD
AF656SHROUD
AF567AMANIFOLD SLEEVE

Positions and part numbers as printed in Gast’s O&M Manual: PISTON_70-2100_M-13.pdf, page 18 · view the source document

Model 5VDF - exploded view · O&M Manual: PISTON_70-2100_M-13.pdf, page 2014 positions

The positions on this drawing haven’t been placed yet: choose a position in the list for its part. Drag to move, pinch or Ctrl + scroll to zoom.

Select a part on the drawing or in the list to see its number, what it fits and where to get it. Turn on “select several” to build one quote for many parts.

Pos.Part numberDescriptionQty
B300AFilter
B300FFILTER
AS100BSAFETY VALVE
AS100DSAFETY VALVE
AS100FSAFETY VALVE
AS100GSAFETY VALVE
AF507CYLINDER HEAD
AF543PLATE VALVE
AF509CYLINDER
AF561DPISTON ROD ASSEMBLY
AF561EPISTON ROD ASSEMBLY
AF561FPISTON ROD ASSEMBLY
AF561KPISTON ROD ASSEMBLY
AF561MPISTON ROD ASSEMBLY
AF561NPISTON ROD ASSEMBLY
AF659MANIFOLD
AB136FSQUARE KEY
AF748FAN/FAN ASSEMBLY-CCW
AF747FAN ASSEMBLY-CW
AF656SHROUD
AF567AMANIFOLD SLEEVE
AF606-1TANK ASSEMBLY
AF550AMANIFOLD
AF550BMANIFOLD
AF550CMANIFOLD
AF550DMANIFOLD
AF550EMANIFOLD

Positions and part numbers as printed in Gast’s O&M Manual: PISTON_70-2100_M-13.pdf, page 20 · view the source document
